Ready to build up your own light and fast trail XC/Trail full suspension mountain bike? Or upgrade your current frame? No better place to start than with a quality and affordable carbon frame. This F110 frame from DIY Carbon BIkes is a light in durable options for those looking for a full suspension with 110mm rear travel. Built with triple enforced T800 Carbon, a 31.6 seat tube for wider posts and dropper posts, and equipped with a durable, stiff, and low maintenance PF92 bottom bracket, this frame is for those looking to be efficient, yet bomb while descending.
This frame is designed in the style of Santa Cruz Tallboy and Blur, and can take 29er or 27.5+ wheels. The frame can take up 100mm-130mm fork in the front with 29er wheels and 120-140mm fork with 27.5+ wheels.
Price: $845 total shipped which includes frame, rear thru axle, headset, and FREE GLOBAL shipping.
Product Specs:
For components for your frame, use our Product Search Tool to compare components from different sites HERE
Material: 100% High-Quality T700/T800 Carbon Fiber
Size Availability: 15.5”,17.5” ,19”, 21”
Finish: UD Matt (Custom Colors available for $75 upgrade for Standard, $150 upgrade for Special Paint -- See options in product images)
Rear Shock Eye to Eye: 165x38
Rear Shock Hardware: 22mmx8mm
Rear Travel: 110mm
Front Fork Travel: 100-130mm 29er wheels (120-140mmmm for 27.5 plus wheels)
Disc Rotor size: 160mm
Weight: 1995g ±30g
Bottom Bracket: PF92
Cable Type: Internal Routing for the brake line, rear derailleur, dropper post.
Rear Spacing: BOOST 12*148mm thru axle (Axle included)
Head Tube: 1-1/8”,1-1/2” integrated 42mm, 52mm cups (Headset included)
Seat Tube: For 31.6mm diameter seat post
Max Tire size: 29x2.5 and 27.5x2.8
Shipping: Frame is shipped Expedited Factory Direct and will arrive in 15-30 days at your door generally. For the most updated and detailed information about shipment see our Shipping and Returns page at the bottom of the site under Support.
Warranty: This frame is eligible for two years full warranty and three years wholesale crash replacement
